Customized lengthen ceramic ball valve delivery to Russia for below applications:
Medium: gas with cat cracking catalyst
Stainless steel body, DN100 (4”) PN10-16 (Class150), wafer, ZrO2 ceramic lining
Working pressure of the medium 0.6 MPa
Design medium pressure 0.8 MPa
Ambient temperature: minus 40 – plus 60
Medium: air with catalyst
Average particle size – 60-100 microns
Catalyst again – aluminum oxide
Pneumatic actuator FC.
Air pressure 3-3.5 bar
